Lenovo Think Station S30
Lenovo Think Station S30
No reviews
See The Best Prices After Login
Lots in Stock : Only 2
Description
Description
Lenovo Think Station S30
| Processor |
Single Intel Xeon E5 series (E5‑1600 v2 or E5‑2600 v2 family), quad‑core up to 12‑core (e.g. E5‑1620 v2 to E5‑2697 v2)
|
| Chipset | Intel Patsburg‑A / Intel C602 PCH supporting ECC DDR3 memory |
| Operating System | Preloaded: Windows 7 Pro/Windows 8 (64‑bit); Supported: Windows XP, Red Hat Linux |
| Memory | Up to 64 GB DDR3 UDIMM (8×8 GB); up to 256 GB using 32 GB RDIMMs (if available); speeds up to 1600 MHz |
| Hard Drive & Storage |
Supports up to ~16 TB HDD (7200 rpm), up to 4 TB 10K, up to 2.4 TB 15K HDDs, up to 1 TB SSD or 8 TB hybrid SATA; RAID‑capable
|
| Graphics Card Support |
Compatible with professional GPU cards—NVIDIA Quadro or NVS series (e.g. Quadro 4000, NVS 310/510) via PCIe x16
|
| Storage Controller | Integrated SATA/SAS support via chipset; optional RAID modules available |
| Warranty | Typically includes 3‑Year Onsite warranty; varies by region and vendor |
| Optical Drive | Tool‑less external 5.25″ drive bays support DVD‑RW drive |
| Networking | Integrated Intel Gigabit Ethernet (Intel 82579 controller); optional WLAN/Bluetooth on certain SKUs |
| Audio | Realtek ALC662 high‑definition audio with front + rear analog jacks; 5.1 channel support |
| I/O Ports | Front: USB and audio connectors; Rear: RJ45 LAN, analog audio, serial, USB, PS/2 ports |
| Drive Bays & Chassis | 31‑liter ATX tower; 2 external 5.25″ bays, 1 external 3.5″ bay, 3 internal 3.5″ drive bays |
| Dimensions | Approx. 19.02″ D × 6.89″ W × 18.82″ H (483 × 175 × 478 mm); weight up to ~38.5 lbs (17.5 kg) |
| Power Supply | 610 W, ~90 % efficient PSU; supports auxiliary cooling fans for high‑end GPUs |
| Noise/Heat Efficiency | Quieter and cooler than comparable systems (e.g. HP Z420); uses ~28 % less power idle, ~14.5 % under load |
| Security & Serviceability |
Tool‑less access for drive bays, memory, optical, expansion cards; TPM support; padlock loop and chassis intrusion switch on supported SKUs
|
| ISV Certification | Certified for major professional applications (CAD, AEC, EDA etc.) |
| Type | Open Box |
Materials
Materials
Standard electronics housing materials
