Eltek Flatpack SMPS Module - 1560 48V/32A 230Vac
Eltek Flatpack SMPS Module - 1560 48V/32A 230Vac
No reviews
See The Best Prices After Login
Lots in Stock : Only 1
Description
Description
Eltek Flatpack SMPS Module
| Product Type | Switched Mode Power Supply (SMPS) Module |
| Model | Eltek Flatpack 1560 |
| Output Voltage | 48V DC |
| Output Current | 32A |
| Output Power | 1560W |
| Input Voltage | 230V AC (nominal) |
| Input Voltage Range | Typically 85–300V AC (wide range compatibility) |
| Efficiency | Up to 96% (typical for Flatpack models) |
| Cooling | Forced air cooling (fan-assisted) |
| Hot-Plug Capability | Yes, hot plug-able for easy maintenance and upgrade |
| Communication Interface | Compatible with Smartpack controllers via CAN bus |
| Form Factor | Compact design for 1U systems |
| Protection Features | Overvoltage, overcurrent, overtemperature, and short-circuit protection |
| Applications | Telecom, data centers, industrial power systems |
| Type | Open Box |
Materials
Materials
Standard electronics materials
